Product specifications
Type: Non-contact forehead thermometer (BNT050)
Measurement range: 34 °C – 43 °C (93.2 °F – 109.4 °F)
Measurement location: Forehead
Resolution: 0.1 °C (0.1 °F)
Laboratory accuracy: ±0.2 °C for the range 35.0 °C – 42.0 °C
(±0.4 °F for 95.0 °F – 107.6 °F)
±0.3 °C (±0.5 °F) for the range outside 35.0 °C – 42.0 °C (95.0 °F – 107.6 °F)
Clinical accuracy: Clinical performance and protocols are available upon request

This thermometer provides a calculated estimate of the oral equivalent
Display: LCD, 4 digits plus special icons
Sound: Audio: 1 beep for 0.4 seconds
User temperature: 15 °C - 40 °C (59.0 °F - 104 °F)
Storage/transport temperature: -25 °C – 55 °C (-13 °F – 131 °F)
Humidity: 15–95% non-condensing
Pressure: 700-1060 hPA (0.7-1.06 atm)
Automatic shut-off: Within approximately 20 seconds
Weight: 93.2g (with batteries) and 71.5g (without batteries)
Dimensions: 55mm x 38mm x 149mm
Long-term storage
Battery: (2) AAA batteries - at least 500 measurements
Device lifespan: 5 years.
Reference site on the body: Mouth

The measured temperature is converted into a value that is equal to a
measurement in the mouth.
The CE marking on this medical device indicates that it has been manufactured
in accordance with the RoHS directive 2011/65/EU and other applicable directives and/or
regulations as specified in the EU declaration of conformity. The
full responsibility to ensure this product meets the standard
is with Kaz Europe Sàrl, Switzerland.
The accuracy requirement of the ASTM laboratory in the display range
from 37 °C to 39 °C (98 to 102 °F) is ± 0.2 °C (±0.4 °F) for
infrared thermometers, while for mercury-in-glass and electronic
thermometers this requirement according to the ASTM standard E 667-86 and E 1112-86
± 0.1 °C (±0.2 °F) is.

What this product is used for
This contactless forehead thermometer is a battery-operated infrared thermometer, intended for occasional measurement of body temperature for home use for people of all ages, except for premature and 'small-for-gestational-age' (SGA) babies, using the center of the forehead for measurement.

Instructions for use
It is important to know what the normal temperature of a person is when they are healthy. This is the only way to accurately diagnose a fever. Take multiple measurements when the person is healthy to determine the normal temperature.
The normal temperature of a child can range between 37.7 °C (99.9 °F) and 36.1 °C (97.0 °F). Please note that this device reads up to 0.6 °C (1.0 °F) lower than a rectal digital thermometer as it provides an oral measurement.
NOTE: The thermometer and the person must be in the same ambient temperature for at least 30 minutes to prevent deviations in the measurement.

Always keep the thermometer and forehead STILL during measurement. Do NOT move the thermometer until you hear a beep (except in silent mode).
Mothers who are breastfeeding should preferably not have their temperature measured by themselves or someone else during and immediately after breastfeeding, as breastfeeding affects body temperature.
Individuals should not drink, eat, or be physically active just before or during measurement. Remove head coverings and wait 10 minutes before measuring.
Remove dirt or hair from the forehead area before measuring the temperature. Wait 10 minutes after cleaning the forehead before taking a measurement.
Always take the temperature exactly as indicated. The measured temperature may vary if the thermometer is placed in the wrong location.
Under the following circumstances, it is advised to take three measurements at the same location and go with the highest value.
• In newborns during the first 100 days after birth.
• In children under 3 years old with a weakened immune system for whom it is crucial to know if they have a fever.
• When the user is learning how to use the thermometer. (Until they are familiar with the instrument and measure consistent values.)
General precautions:
• Wipe away dirt or sweat from the forehead area with a dry cloth before measuring the temperature.
• Do not place cooling or warming materials on the forehead at least 30 minutes before the measurement.
• Remove blankets and pillows from the head and face before measuring the temperature.
• DO NOT take measurements in areas where there is scar tissue, open wounds, or abrasions.
• Always store the thermometer in a dry, clean environment. Do NOT store the thermometer in a place with sharp objects that could damage the sensor. Dirt, dust, and scratches affect the accuracy of temperature measurements.

1. Turn On
Press the power button. The backlight will turn on, the startup begins, and you will hear a beep.
If a temperature has been measured previously, the screen will display the last measured temperature before it goes to the Ready screen.
2. Ready
When the device is ready, three dotted lines will be displayed on the screen.
3. Position
Place the thermometer 1-5cm from the center of the forehead, right between the eyebrows.
If there is hair, sweat, or dirt in the eyebrow area, clean the area beforehand to ensure the
increase measurement accuracy. It is important to keep the thermometer and forehead still during the
measuring. When these move, it affects the temperature measurement.
4. Take temperature
Press the temperature button to take the temperature.
The device measures and you will hear a beep when the measurement is complete.
5. Read temperature
Read the temperature.
6. Turn off
Press the power button to turn off the device. If the device is not used for 20 seconds, it will automatically turn off. The word 'OFF' appears on the screen when the device begins to shut down.

Switch the temperature unit between °C and °F
1. While the device is off, press and hold the speaker button for 4 seconds. The display switches between °C
and °F.
2. Select which measurement unit you want by pressing the speaker button again. The display stops
switching between ºF and ºC and remains on the selected unit.
3. After 3 seconds, the thermometer will automatically turn off.
4. The selected measurement unit will be displayed
during the startup of the thermometer.

Change the sound mode
To activate silent mode, press and hold the 'sound mode' button. The speaker icon changes to a muted icon on the display, indicating that silent mode is enabled.

To turn off silent mode, press the 'sound mode button' again. The muted icon changes back to the regular speaker icon.

Calibration
The thermometer is calibrated during production. If this thermometer is used according to the instructions, it does not need further adjustment. If you have doubts about the accuracy, contact customer service.

Maintenance and cleaning
Use an alcohol wipe or cotton pad with alcohol (70% isopropyl) to clean the casing of the thermometer and the measuring probe. Ensure that no liquid enters the thermometer. NEVER use aggressive
cleaning agents, thinners, or benzene for cleaning and NEVER immerse the instrument in water or other cleaning liquids. Ensure that no scratches occur on the lens of the thermometer by replacing the protective cap after
to replace the use. NEVER insert a sharp object into the scanning area or other openings of the thermometer.

Replacing the batteries
The Braun Sensian™ 3 thermometer comes with 2 AAA batteries.
Replace the batteries with 2 new AAA batteries when the flashing battery symbol appears on the LCD screen. Replace the batteries by sliding open the battery cover and removing the batteries. Place the
new batteries and ensure they are properly aligned as indicated in the battery compartment. If you do not use the product for an extended period, you should remove the batteries. This prevents damage from leaking batteries.
Only dispose of empty batteries. They must not be thrown away with household waste, but should be returned to designated collection points or your point of sale.

There are still works until 0% of the lifespan is left. Replace the batteries.
If the battery symbol is the only symbol displayed, the device is not working.
The battery must be replaced immediately.

Replace the batteries.
This message is displayed when the measured temperature is lower than 34 °C (93.2 °F) or higher than 43 °C (109.4 °F), or
when the ambient temperature is outside the operating range of 15 – 40 °C (59 – 104 °F).
Measure the temperature again and carefully follow the instructions under "How to use the Braun Contactless +"
forehead thermometer?

Display black. The thermometer is empty. Check if the batteries are properly installed. Also check the polarity.
(<+> and <–>) of the batteries. Contact customer service if the thermometer still does not work.

System error - the display with the self-test keeps flashing continuously and there is no beep or symbol afterwards
that indicates the device is ready: Wait 1 minute until the thermometer automatically turns off and turn the device back on.

Contraindications
This thermometer is not intended for clinical use in a professional environment, but solely for home use.
This thermometer is not intended for interpreting hypothermic temperatures. If the device indicates a temperature of 35.7 °C (96.3 °F) or lower and the person exhibits atypical symptoms or behaviors, contact your general practitioner or other doctor.
This thermometer is not intended for premature babies or babies who are small for their gestational age. A premature baby is defined as a baby born before 37 weeks of pregnancy. Small for gestational age is defined as a newborn baby (birth to 4 weeks old), born at 37 weeks or later, with a weight below the 10th percentile for newborns of the same gestational age.
The use of this thermometer is not a substitute for a consultation with your doctor

Ingredients
1 x Braun Sensian non-contact thermometer 2 x 1.5V AAA RL03

Warnings
Keep out of reach of children under 12 years old.
Never use the thermometer for purposes other than those for which the
the thermometer is intended. Adhere to the general
safety precautions when using the thermometer with children
used.
Never immerse the thermometer in water or other liquids (the
the device is not waterproof). Follow the instructions in
the part “Care and cleaning.”
Do NOT store the thermometer at an extreme temperature lower than -25 °C
(–13 °F) or higher than 55 °C (131 °F) or in a too humid space (more than 95%
relative humidity without condensation).
If the thermometer is stored in a place that is cooler or warmer than the
location where the thermometer is used, let the thermometer
come to room temperature for 30 minutes before measuring.
A person must be indoors for at least 30 minutes before their
temperature is being measured. If the person is indoors but in a room that
more than a few degrees warmer or colder than the room in which the
if the thermometer is located, it will affect the accuracy of the
thermometer.
Do not use the thermometer if the scanner or the thermometer itself shows signs
shows signs of damage. If damaged, you must NOT attempt to
repair.
NEVER insert a sharp object into the scanning area or into other
openings of the thermometer.
This thermometer consists of high-quality precision components.
Do NOT drop the instrument. Protect it from heavy impacts and
shocks.
Do not use the device if it is damaged in any way,
degraded or detached. The effects of damaged sensors and
electrodes, or loose electrodes, which can reduce performance or
can cause other problems.
A raised temperature may indicate a serious illness, especially in
(newborn) babies and in adults who are elderly, or who have a weak
health or have a reduced immune system. Consult
a raised temperature occurs in:
• Newborns younger than 3 months (consult your doctor immediately if
doctor if the temperature is higher than 37.4 °C (99.4 °F)
• People aged 60 and older (fever can occur in older individuals)
suppressed or absent)
• People with diabetes mellitus or a weakened immune system
(for example, due to an HIV-positive status, chemotherapy for cancer,
chronic treatment with immunosuppressants, removed spleen)
• Bedridden individuals (for example, patients in nursing homes, people
who have had a stroke, people with paraplegia or quadriplegia,
people with a chronic illness or those recovering from surgery
recovering)
• Transplant patients (after, for example, a liver transplant,
heart, lungs or kidneys).
DO NOT allow children to measure their own temperature without supervision.
Consult your doctor for symptoms such as unexplained irritability,
vomiting, diarrhea, dehydration, changes in appetite or activity,
seizures, muscle pain, shivering, a stiff neck, and pain when urinating, even if there are
no fever present.
People with a normal temperature can also be without
fever may need medical assistance. The condition of individuals who
taking antibiotics, pain relievers, or antipyretics should not be the only
are assessed based on temperature measurements to determine the severity of their
determine illness.
DO NOT modify this device without the manufacturer's permission.

Storage advice
Keep the instructions and the thermometer in a safe place.

Additional information
Medical device. Read the instructions for use before use.

Manufacturer / Distributor
Kaz Hausgeräte GmbH, Kölner Strasse 23, 57439 Attendorn, Germany
